SKU/Artículo: AMZ-B07RFSBR27
Focket
DC 5V-36V Time Delay Relay Module, Timer Relay, Delay Switching Relay Module,Timer Switch with LED Display
Detalles del producto
Disponibilidad:
En stock
En stock
Peso con empaque:
0.36 kg
0.36 kg
Devolución:
Sí
Sí
Condición
Nuevo
Nuevo
Producto de:
Amazon
Amazon
Viaja desde
USA
USA
Sobre este producto
- Specifications: Voltage: DC 5V~36V. Source: High voltage level (3.0V~24V), ground and system ground are not on common ground to improve the system's anti-jamming capability (you can also connect them on common ground). Output Capacity: DC 5V~36V, at room temperature, continuous current is 15A, power 400W. With enhanced heat dissipation, the current can be up to 30A. Quiescent Current: 20mA Operating Current: 50mA Working Temperature: -40℃~85℃ Clocking (Time Delay) Range: 0.1seconds to 999minutes Size: 60*34*12mm / 2.36*1.33*0.47" Parameter Description: "OP" - on time, "CL" - off time, "LOP" - number of cycle times (1- times, "---" represents infinite loop). These parameters are independent of each other, but are shared by each mode. For example, in P1.1 mode, set the on-time "OP" is 5 seconds, if you switch to P1.2 mode, its "OP" will also be 5 seconds. In the main interface (display 000), press "SET" button will display "OP" ( "CL", "LOP") and the corresponding time XXX; If the mode (such as the mode P1.1, P1.2, P1.3) only has "OP" time, press the "SET" key to display only the "OP" and the corresponding time; Some (such as the mode P3.1, P3.2) have parameters "OP", "CL", "LOP", press "SET" button will display "OP" and the corresponding time, "CL" and the corresponding time, "LOP" and the corresponding number of times; After setting mode, in the main interface press "SET" key to see information about the parameters of the current mode, very convenient. Package Includes: 1 x Timer Switch Module
U$S 9,63
49% OFF
U$S 4,94
IMPORTÁ FACIL
Comprando este producto podrás descontar el IVA con tu número de RUT
U$S 9,63
49% OFF
U$S 4,94
Llega en 5 a 11 días hábiles
con envío
Tienes garantía de entrega
Conoce más detalles
【 AND 】No noise was made during turning on/off, no spark, and no electromagnetic interference.To achieve fast turn-on and off circuit, an unlimited number of switching times. 【HIGH PRECISION】Dual-MOS in parallel active output, lower inner , larger current, strong power; at room temperature, operating current is up to 15A, power up to 400W, that can be used for most equipment. 【SLEEP MODE】It has an emergency stop function (""STOP"" button) and reverse input .Automatically enter sleep mode and shut off display if no in 5 minutes, and will be wake up by pressing any button. 【INDEPENDENT PARAMETERS】You can set different OP, CL, LOP parameters, which are independent of each other, and are saved separately;All parameter settings will be saved automatically if there is a power failure. 【SCOPE OF APPLICATION】Timer module widely used on timer operating equipment, robots, intelligent product development, automation equipment, PLC development, smart home anti-theft alarm delay, electronic development, etc.
