USR-TCP232-302 Serial RS232 to Ethernet TCP IP Server Module Ethernet Converter Support DHCP/DNS
En stock
0.39 kg
Sí
Nuevo
Amazon
- USR-TCP232-302 is a low-cost serial device server,whose function is to realize bidirectional transparent transmission between RS232 and Ethernet.
- USR-TCP232-302 is internally integrated with TCP/IP protocol. User can apply it to device networking communication.
- Support DHCP, automatically obtain an IP address and query IP address through serial setting protocol
- Work mode: TCP Server, TCP Client, UDP Client, UDP Server, HTTPD Client
- The global unique MAC address bought from IEEE, user can define MAC address? Can work in LAN, also can work in the Internet (external network)
IMPORTÁ FACIL
Comprando este producto podrás descontar el IVA con tu número de RUT
Conoce más detalles
PUSR USR-TCP232-302 Serial RS232 to Ethernet TCP IP Server Module Ethernet Converter Support DHCP/DNS Features of RS232 Ethernet ServerSupport DNS functionSet parameters through webpageUpgrade firmware via networkAuto-MDI/MDIX, RJ45 port with 10/100MbpsSerial port baud rate from 600 bps to 230.4 Kbps, Check bit of None, Odd, Even, Mark and SpaceSupport virtual serial port and provide corresponding software USR-VCOMHeartbeat package mechanism to ensure connection is reliable, put an end to dead linkUser-defined registration package mechanism, check connection status and use as custom packet headerUnder TCP Server mode, Client number ranges from 1 to 16; default number is 4Across the gateway, switches, routersProvide PC TCP/IP socket programming example such as VB,C++,...Application Field of RS232 Ethernet ServerIndustrial data transmission, industrial automationsecurity and protection monitoring, public securitySmart home, power control, environmental monitoring, intelligent agricultureDoor check on work attendance system, POS system, rice selling systemBuilding automation system, power monitoring, self-service banking system, telecom machine room monitoring
