SKU/Artículo: AMZ-B0B6CNC6MM

Generic

3PCS Analog Current Meter Sensor Module AC 0~5A Ammeter Sensor Board Based on ZMCT103C for Arduino

Detalles del producto
Disponibilidad:
En stock
Peso con empaque:
0.36 kg
Devolución:
Condición
Nuevo
Producto de:
Amazon
Viaja desde
USA

Sobre este producto
  • Instructions: During measurement, the wire under test passes through the round hole of the current transformer, VCC and GND are connected to the 5-30V power supply, VOUT and GND are connected to the oscilloscope, and the potentiometer is adjusted to obtain the desired waveform. The amplitude of the output waveform will increase with the increase of the measured wire current, but the amplitude of the output waveform will not exceed 50% of the input power supply voltage VCC. Package : 3 x Current Transformer Module
U$S 20,88
55% OFF
U$S 9,49

IMPORTÁ FACIL

Comprando este producto podrás descontar el IVA con tu número de RUT

U$S 20,88
55% OFF
U$S 9,49

¡Comprá en hasta 12 cuotas sin interés con todas tus tarjetas!

Llega en 5 a 11 días hábiles
con envío
Tienes garantía de entrega

Conoce más detalles

Analog ammeter module. Transformers can only sense alternating current This power sensor is based on ZMCT103C current transformer, which can convert high-current AC signal into small-amplitude signal. Rated input current 5A, rated output current 5mA Transformation ratio: 1000:1, isolation withstand voltage 3000V Supply voltage: 5-30V
