SKU/Artículo: AMZ-B0DHSVRLY8

Walfront

PLC with High Speed Counting Programmable Logic Controller Board 32 Input 28 Output 2/100K Support RS232 RS485 DC24V Power Supply

Disponibilidad:
En stock

Peso con empaque:
0.92 kg

Devolución:
No

Condición
Nuevo

Producto de:
Amazon

Sobre este producto

Download and Comm: Supports 1 way RS232 and 1 RS485 comm port, can communicate with programming software simultaneously; Download speed compatible with 9.6-11.52Kbps, supports programming, downloading, debugging, and monitoring (does not support monitoring writing)
Touch Screen Comm: The three communicating ports can communicate with the touch screen simultaneously, for FX3U protocol selected and comm parameters of 19200, 7, E, 1, with strong compatibility
Power Supply: The PLC control board is powered by DC24V, and under the condition that the output relay is not turned on, the static current is 40MA, and the starting current needs to be 1A
Analog Input Output: Default 4AD 0-10V input, 2DA 0-10V output; 6 ways high speed input, X0/100K, X1-X5/10K (X0 and X1 use as phase 100K); High speed output Y0-Y5 200kHz Y6-7 100kHz
Enhanced Security: Enables super encryption function with keyword 12345678 to prevent program upload and password modification, clearing program upon password change to deter password cracking software

U$S 284,93

60% OFF

U$S 113,97

U$S 284,93

60% OFF

U$S 113,97

Llega en 25 o más días hábiles

Tienes garantía de entrega

Cantidad

Este producto viaja de USA

a tus manos en

Medios de pago Aceptamos múltiples medios de pago para tu comodidad

Compra protegida

Disfruta de una experiencia de compra segura y confiable

¿Qué es Tiendamia?

Fácil, rápido y seguro

Garantía de entrega

100% garantizada

Devoluciones

dentro de los primeros 7 días de recibido

Pago 100% seguro

con todas las tarjetas

Información de Aduanas

para tu compra

Sé un Ciudadano de Tiendamia

para beneficios extra

Únete ahora

Ayuda y atención

Consulta el centro de ayuda en línea

Contáctanos

Tarjetas prepagas, debito, y credito

Paga hasta en 12 cuotas sin interés con tarjetas de crédito.

Conoce más detalles

Specification: Item Type: PLC Control Board Material: ABS Size: Approx. 225 x 110 x 78mm / 8.9 x 4.3 x 3.1in Download Speed: 9.6-115.2Kb Memory Capacity: 32000 Steps Input Points: 32 Output Points: 28 Output Type: Relay Output Current: 3A Load: 24V/220V High Speed Count: 2/100K Pulse Output: None Analog Input: 4AD 0-10V Analog Output: 2DA 0-10V 485: 1 Way 232: 1 Way Power Supply: DC24V How to Use: Follow the electronic manual for instructions packing list: 1 x PLC Control Board 1 x Download Cable (3 Meter)
