JESSINIE 5V 30A Relay Module, 1 Channel, Optocoupler Isolation, High/Low Trigger for Automation Control

Color:

12V

24V

Detalles del producto

Disponibilidad:
En stock

Peso con empaque:
0.36 kg

Devolución:
Sí

Condición
Nuevo

Producto de:
Amazon

Viaja desde
USA

Sobre este producto

Product parameters: Module size: 50mm * 33mm* 24mm (length * width * height) There are 4 fixing bolt holes, the hole is 3.1mm, the spacing is 44.5mm*27.5mm Parameter: 5V Relay module Quiescent current: 5mA Maximum current: 190mA Trigger current: 2-4mA Trigger power (low): 0-1.5V High: 2.5-5V 12V Relay module Quiescent current: 5mA Maximum current: 80mA Trigger current: 2-4mA Trigger power (low): 0-4V High: 4.5-12V 24V Relay module Quiescent current: 5mA Maximum current: 50mA Trigger current: 2-4mA Trigger power (low): 0-8V High: 8.5-24V Pin description: 1. DC+: Module DC power supply anode (trigger terminal voltage anode) 2. DC-: Module DC power supply negative electrode (trigger terminal voltage negative electrode) 3.IN: Signal trigger terminal (default trigger voltage is the same as power supply) 4.JD+: Positive voltage of relay control terminal 5.JD-: The negative pole of the control terminal voltage of the relay 6. Short-circuit DC+ and JD+ with jumper caps, and short-circuit DC- and JD- with jumper caps. The trigger terminal and the relay control terminal have the same voltage 7. High and low level trigger mode selection, as shown in the figure, when the jumper is connected to the L terminal, the IN terminal is a low level trigger, and when it is connected to the H terminal, it is a high level trigger 8. Normally closed terminal (NC): normally closed terminal of the relay 9. Common terminal (COM): relay common terminal 10. Normally open terminal (NO): Relay normally open terminal

U$S 14,23

55% OFF

U$S 6,47

U$S 14,23

55% OFF

U$S 6,47

Llega en 5 a 11 días hábiles

con envío

Tienes garantía de entrega

Medios de pago

Cantidad

Medios de pago

Conoce más detalles

**Versatile Automation Control**: This 5V 30A relay module offers seamless integration for automation projects, featuring optocoupler isolation for enhanced signal integrity, making it ideal for smart home systems and industrial applications. **User-Friendly Design**: Easily switch between high and low trigger modes with a simple jumper cap configuration. Designed to be intuitive, ensuring hassle-free setup even for beginners. **Reliable Performance**: Built with high-quality power relays and military-grade double-sided PCB, ensuring stable performance and long-lasting durability in various power control applications. **Compact and Efficient**: With a compact size of 50mm x 33mm x 24mm, this module delivers powerful performance without taking up much space, perfect for projects with limited room. **Wide Compatibility**: Suitable for 5V, 12V, and 24V systems, accommodating a wide range of projects. Red and green signal indicators provide clear status visibility, enhancing operational safety and efficiency.
