SKU/Artículo: AMZ-B0FKJJDW5F

Hyuduo

Hyuduo Variable Frequency Drive VFD Vector 3 Phase Inverter Controller Converter 380V 18KW 22KW, Magnetic Flux Braking, Start Speed Tracking, Wide Speed Adjustment, Stainless Steel

Disponibilidad:
Fuera de stock

Peso con empaque:
11.16 kg

Devolución:
No

Condición
Nuevo

Producto de:
Amazon

Sobre este producto

[Wide Speed Adjustment] A wide range for speed adjustment and stability.
[Efficient Motor Startup] Magnetic flux braking and current limiting for rapid motor start and stop.
[Precise Speed Control] Quick start speed tracking identifies motor direction with .
[Versatile Application] Ideal for petrochemical, air compressor, cnc machine tool, and more.
[Easy Operation] Connects to an external keyboard for convenient use, monitor light displays running status.

Fuera de stock

Selecciona otra opción o busca otro producto.

Este producto viaja de USA

a tus manos en

Medios de pago

Conoce más detalles

Spec: Item Type: Variable Frequency Drive Product Material: Stainless Steel Product Model: CM530H-4T018GB/022PB Input Voltage: 3 phase 380V. Voltage Range: -15%~20% Input Current: 38.5/46.5A Output Current: 37.0/45.0A Adapted Motor: 18KW/22KW Control Mode: Open loop (SVC), V/F control. Speed Adjustment Range: 1:200 (open loop ). Maximum Frequency: : 0~600HZ, VF control: 0~1200HZ. Carrier Frequency: 1k~15kHZ Application Scenarios: Mainly used in the industries of fan and , petrochemical industry, air compressor, extruder, CNC machine tool, hoisting machinery, textile machinery, plastic machinery, woodworking machinery, ceramic machinery, stone machinery and other industries. Package List: 1 x Variable Frequency Drive 1 x User Manual Note: 1. It is not suitable to use the inverter outside the allowable working voltage range specified in the user manual, which may easily cause damage to the internal components of the inverter. If necessary, please use the corresponding step up or device to transform the power supply and input it to the inverter. 2. Do not change the 3 phase inverter in the CM series to 2 phase use, otherwise it will cause a malfunction or damage the inverter. 3. Although this series of inverters are equipped with over current protection devices, which have a certain self protection ability against induced , users should also install protection devices on the front of the inverter for places where is frequent.

Hyuduo Variable Frequency Drive VFD Vector 3 Phase Inverter Controller Converter 380V 18KW 22KW, Magnetic Flux Braking, Start Speed Tracking, Wide Speed Adjustment, Stainless Steel
