FEETECH FS90R (5 Pack) - 360 Degree Continuous Rotation Servo 9g for Robotic Helicopter Airplane Boat
En stock
0.36 kg
Sí
Nuevo
Amazon
- Dual High Rotation:This micro servo rotates 360 degrees fully forward or backwards,well-controlled, perfect for robot joint activities
- Great Compatible: Arduino and Raspberry Pi compatible
- Lightweight,Small dimensions,especially fit in small spaces
IMPORTÁ FACIL
Comprando este producto podrás descontar el IVA con tu número de RUT
Conoce más detalles
Description: The FS90R is an analog micro servo that is capable of continuous rotation clockwise or anti-clockwise, as opposed to moving to a set position. The servo can be controlled using any servo code, hardware or library and to control with an Arduino, just connect the orange control wire to pin 9 or 10 and use the Servo library included with the Arduino IDE. Good for beginners who want to make stuff move without having to use a motor controller, especially since it will fit in small places. They may require some simple calibration, simply tell the servo to 'stop' and then gently adjust the potentiometer in the recessed hole with a small screwdriver until the servo stops moving. Specification: Dimensions:23.2 × 12.5 × 22 mm Weight:9 g Operating Speed : 110RPM (4.8V) 130RPM (6V) Stall Torque : 1.3kg.cm/18.09oz.in(4.8V) 1.5kg.cm/20.86oz.in(6V) Operating Voltage: 4.8V~6V Control System: Analog Direction: CCW Operating Angle: 360degree Required Pulse: 900us-2100us Bearing Type: None Gear Type: Plastic Motor Type: Metal Connector Wire Length: 20 cm Document link http://www.diymalls.com/files/FZ0101-01-FS90R-Servo.pdf Package Inlcuding: 5 X Feetech FS90R Servo
