Delay Relay Module DC12V 0-120min Adjustable Timer On/Off Time Delay Relay Timing Switch Module Board Delay for Industrial Control(DC 12V 0-120min)

Detalles del producto

Disponibilidad:
En stock

Peso con empaque:
0.36 kg

Devolución:
Sí

Condición
Nuevo

Producto de:
Amazon

Viaja desde
USA

Sobre este producto

Specifications:Type: DC12V,0-120minQuiescent Current: <10mA Dynamic Current: 45mA@12V; 90mA@5V; 30mA@24V: 1 group NO+NC Load acity: 10A(AC0-250V, DC0-30V） Size: 70*20*18mm / 2.75*0.78*0.7" Time Accuracy: maximum value*0.001 Mon. Mode: 1. The module Power-on, When triggered the relay is switched on, timer delay off. 2. When triggered on the delay process, again triggered, it will immediately interrupt the delay. Cycle Mode: 1. The module Power-on, When triggered the relay is switched on, (T1) timer delay off. (T2) timer delay on. Such cycle. T1 and T2 are set by two adjustable resistors, respectively. 2. When triggered on the delay process, again triggered, it will immediately interrupt the delay. Package Includes:1 x Timer Relay Module

U$S 18,72

44% OFF

U$S 10,40

U$S 18,72

44% OFF

U$S 10,40

Llega en 5 a 11 días hábiles

con envío

Tienes garantía de entrega

Medios de pago

Cantidad

Medios de pago

Conoce más detalles

Versatile Timer Modes: This Timer Relay Module offers two distinct modes—mon mode (once) and cycle mode—allowing you to tailor its functionality to your specific needs. Switching between modes is as simple as adjusting a jumper, making it user-friendly for various applications. Whether you require a single delay action or a repetitive cycling function, this module has you covered with its flexible operation Adjustable On/Off Timing: With both “on” time and “off” time being fully adjustable, this timer relay module provides exceptional control over your timing requirements. Choose from a variety of voltage and time ranges, including options up to 120 minutes. This adaptability ensures you can fine-tune the module to perform precisely as needed, whether for intermittent pumps, machine testing, or other timer-based applications Reliable and High Precision: Built for reliability and consistent performance, this timer relay module boasts high precision in its timing functions. With a time accuracy of max value*0.001, you can depend on it for critical timing applications where . Its stable operation ensures that your projects will run smoothly without unexpected delays or errors, making it a trusted component for various electrical setups Robust Load Capacity: The Timer Relay Module is designed to handle substantial loads with a capacity of up to 10A (AC0-250V, DC0-30V), making it suitable for more demanding applications. This robust capability opens up a wide range of possibilities, from operating high-power devices to managing various machines and equipment in an industrial setting, ensuring it can support your projects effectively Easy Integration and Installation: Designed for plug-and-play functionality, this timer relay module can be easily integrated into your existing system. Its compact dimensions (70*20*18mm) make it suitable for tight spaces, while the quiescent current of less than 10mA ensures efficient energy use. With straightforward connection instructions, you can quickly implement this module into your projects without extensive modifications or complications
