RATTMMOTOR CNC Spindle Motor Kit 110V 2.2KW Water Cooled 80mm Spindle Motor ER20 24000RPM 400HZ+2.2KW VFD 110V Single to 3 Phase Inverter Variable Frequency Drive+Mount Clamp+Water Pump+ER20 Collet
Size:
110V
Disponibilidad:
En stock
En stock
Peso con empaque:
9.98 kg
9.98 kg
Devolución:
Sí
Sí
Condición
Nuevo
Nuevo
Producto de:
Amazon
Amazon
Sobre este producto
- 【Package Include】: ①1 x 2.2KW Water Cooled Spindle Motor ②1 x 2.2KW VFD ③1 x 80mm Spindle Motor Mount(with 3pcs screws) ④1 x 80W Water Pump ⑤1 x 5m Pipe ⑥1 x ER20 Wrench ⑦14 x ER20 Collet（1mm, 2mm, 3mm, 3.175mm, 4mm, 5mm, 6mm, 7mm, 8mm, 9mm, 10mm, 11mm, 12mm, 13mm）
- 【2.2KW Spindle Motor】: ①This is a 110V-2.2KW water-cooled 15A Φ 80x213mm spindle motor come with a ER20 nut and collet. Frequency is 400HZ, 0.003--0.005 accuracy and runout off is Less than 0.02mm. ②Speed of The Spindle Motor : 0-24000RPM. Because it is a high-speed spindle motor, the spindle speed must not be lower than 9000 rpm during the use of the spindle. It should be noted that the spindle only can rotate clockwise but not counterclockwise.
- 【2.2KW VFD】①Parameters: Input Voltage: 110V(+/-15%), Output Voltage: 110VAC, Input Frequency: 50-60 Hz, Output Frequency: 0-1000 Hz, Input Phase: 1 phase, Output Phase: 3 phase. It provide a variety of fault protection functions: over-current, over-voltage, under-voltage, over-heat, overload, lack of equal real-time monitoring and protection to ensure safe operation.
- ②Other Fuctions: With over torque and under torque detection; With jump frequency control function, it can effectively suppress mechanical resonance and make the system more stable and reliable.It can also avoid the impact of production due to instantaneous power failure because of instantaneous power-down retention function. What's more, it supports multiple frequency settings: digital setting, analog setting, PID setting, RS485 communication setting,ect.
- 【How to Connect Spindle Motor and VFD】The spindle motor's aviation plug marked with number 1, 2, 3, 4. Number 1, 2, 3 port are connected with inverter's port U, V, W respectively. Number 4 is the ground wire, no wiring is required.
