SKU/Artículo: AMZ-B0FGQBC64V

Ueekkoo

ESP32-S3 3.16inch Display Development Board, ESP32 with Display 320×820, 262K Color, 32-bit LX7 Dual-core Processor, WiFi & Bluetooth 5, RGB Interface, Support Landscape Display via Software

0 5 5 2

2 calificaciones

Disponibilidad:
Fuera de stock

Peso con empaque:
0.36 kg

Devolución:
No

Condición
Nuevo

Producto de:
Amazon

Sobre este producto

Equipped with high-performance Xtensa 32-bit LX7 dual-core processor, up to 240MHz main frequency. Supports 2.4GHz Wi-Fi (802.11 b/g/n) and Bluetooth 5 (LE), with an onboard antenna. Supports switching to use external antenna via resoldering an onboard resistor. Built-in 512KB SRAM and 384KB ROM, with onboard 16MB Flash and 8MB PSRAM.
Onboard 3.16inch LCD display which can smoothly run GUI programs such as LVGL. 320x 820 resolution, 64K color, RGB565 communication interface. 550 cd/㎡ Brightness.
Onboard QMI8658 6-axis IMU (3-axis accelerometer and 3-axis gyroscope) for detecting motion gestures, counting steps, etc. Onboard PCF85063 RTC chip for RTC functionality requirement, with reserved SH1.0 RTC battry header.
Onboard slide switch for power ON/OFF, offering better control and reliability. Onboard RST button and BOOT programmable button for easy custom function development.
Onboard 3.7V MX1.25 Lithium battry recharge/discharge header. Onboard TF card slot for external TF card storage of pictures or files.
Reserved UART, SH1.0 4PIN I2C, and MX1.25 4PIN USB headers. Onboard USB Type-C port for power supply, program downloading, and debugging, more convenient for development use.
Comes with Online Development Resources and Tutorials to help you get started quickly: bit.ly/4lgbqNA
